0.25 cu in 9 GPM 4 Section Rotary Flow Divider MTE P205R-5469 [903134]

Product Description

25:25:25:25 ROTARY FLOW DIVIDER
Brand new, MTE 200 series model P205R-5469. Hydraulic gear type rotary flow dividers. Accurately divide flow from one source into two or more equal proportionate flows. Relief valves do not limit system pressure, they only limit differential pressure from outlets to inlet.

SPECIFICATIONS

• Flow Division 25:25:25:25
• Displacement per Section 0.251 cu.   in. /rev.
• Input Flow
    Minimum Input 8.69 GPM
    Maximum Input 19.56 GPM
• Output Flow per Section
    Minimum Input 2.173 GPM
    Maximum Input 4.89 GPM
• Pressure
    Maximum Input 3000 PSI
    Maximum Output 3500 PSI
• Factory Set Differential PSI Between Sections 750 PSI
• Relief Valves Adj. Range 500 - 1000   PSI
• Inlet Port SAE 10
• Outlet Port SAE 8
• Mount Base four bolt on 10.2" x 2"
• Size 10.94" x 3.94" x 4.66"
• Shpg. 21 lbs.
