Product Description
SINGLE SPOOL 20 GPM TANDEM CENTER CONTROL VALVE DETENT
New BMG C-908-C, 4-way 3-position tandem center single spool valve. Used for control valve on log splitters. Spring centered in one direction, and pressure released detent in the other direction. Automatically kicks back to neutral when cylinder completes stroke. Includes built-in adjustable inlet relief valve.
SPECIFICATIONS
- Brand BMG
- Model Number C-908-C
- Tandem Center
- Spools 1
- Spool Type 4 Way 3 Position
- Flow 20 GPM
- Pressure 2500 PSI
- Relief Valve Setting 2000 PSI
- In/Out Ports 3/4" NPT
- Work Ports 1/2" NPT
- Mount Four 3/8"-16 threaded holes on 2.625" x 1" centers
- Handle Length 7.8"
- Size 9.5" x 4.06" x 3.05" w/o handle
- Shpg 10 lbs.
Spool Details:
Spool 1 Double Acting cylinder spool, spring to center w/ detent
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Badges surplus-item,last-one
Dimensional Diagram dr907129.pdf
Max Flow 20 GPM
Spool Type Cylinder
Spools 1
Valve Type Tandem Center
