Product Description
117.29:1 SIZE 147 20 HP INLINE GEAR REDUCERBrand new, World Wide Electric helical inline speed reducer. Cast iron housings. Drop-in replacement for most major inline reducer brands. Gearbox flanges are designed to accept NEMA C-Face electric motors.
SPECIFICATIONS
- Model Number WINL147-120/1-254/6TC
- Box Size 147
- Stages 3
- Nominal Ratio 120:1
- Actual Ratio 117.29:1
- Output RPM @ 1800 RPM Input 15 RPM
- Input Hp 20 Hp Max
- Output Torque 77567 in.-lbs. Max
- Over-Hung Load 13640 lbs. Max
- Service Class I
- Motor Mount 256TC
- Output Shaft 4.375" dia. x 8.27" long keyed, 1" wide keyway, shaft end tapped 1"-8
- Base Mount Four 1.54" holes on 19.69" x 14.96" centers
- Shpg. 981 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Truck true
Prop65 true
Legacy Part Number 13-1560-120-256TC
Badges drop-ship
Input HP 20
Motor Mount 256TC
Nominal Ratio 120:1
