![11 Tooth 1/2" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/1280x1280/products/2313/101091/1-2413-11-A__52242.1762806515.jpg?c=1 "11 Tooth 1/2\" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]")
![11 Tooth 1/2" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/1280x1280/products/2313/101092/1-2413-11-A_1__45949.1762806515.jpg?c=1 "11 Tooth 1/2\" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]")
![11 Tooth 1/2" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/100x100/products/2313/101091/1-2413-11-A__52242.1762806515.jpg?c=1 "11 Tooth 1/2\" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]")
![11 Tooth 1/2" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/100x100/products/2313/101092/1-2413-11-A_1__45949.1762806515.jpg?c=1 "11 Tooth 1/2\" Bore 35 Pitch Roller Chain Sprocket 35BS11H-1/2 [601065]")
Product Description
35 PITCH ANSI ROLLER CHAIN SPROCKETBrand new. ANSI standard 35 pitch roller chain sprocket. Bored to size. One-piece carbon steel forged construction with hardened teeth and black oxide finish. Two set screws. Set screws are located directly over the keyway and 90° from keyway. Keyway is on center line of tooth.
SPECIFICATIONS
- Pitch 35
- Number of Teeth 11
- Bore Size 1/2"
- Model Number 35BS11H-3/4
- Outside Diameter 1.50"
- Hub Diameter 1-1/16"
- Hub Type B (Hub on one side)
- Length Through Bore 3/4"
- Keyway Size 1/8" wide x 1/16" depth
- Shpg. 0.3 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 1-2413-11-A
PDF Page Catalog298-116.pdf
Badges regular-stock
Bore Fractional 1/2''
Pitch 35
Teeth 11
