13" 571 CFM 24 Volt DC Fan SF1324434 [501234]

Product Description

13" GRILL 571 CFM 24 VDC FILTER FAN
New, Pentair fresh air enclosure thin filter fan model SF1324434. High airflow and low noise for cooling electrical equipment or general air circulation. Grey plastic grill. Air is pulled through the plastic grill and filter. Metal housing with plastic blades. Click-fit design installs into enclosure wall. Snap over grill with foam filter. 70db rating. Terminal block electrical connection.

SPECIFICATIONS

• Pull Type Fan
• Model Number SF1324434
• Flow 571 CFM max.
• Voltage 24 DC
• Amperage 5 Amps
• Power 105 Watts
• Speed 2750 RPM
• Operating Temperature Range Min. 5° F to Max. 140° F
• IP Rating 54
• Mount 8 holes on 5-15/16" to 11-7/8" x 5-15/16" to 11-7/8" centers
• Cutout Dimensions 11.5" x 11.5"
• Blade Dia. 9-7/8"
• Number of Blades 7
• Size 12-3/4" x 12-3/4" x 5-1/2"
• Shpg. 14 lbs.
