13" 571 CFM 400/460 Volt AC Fan SF1346433 [501238]

Product Description

13" GRILL 571 CFM 400/460 VAC FILTER FAN
New, Pentair fresh air enclosure filter fan model SF1346433. High airflow and low noise for cooling electrical equipment or general air circulation. Black plastic grill. Air is pulled through the plastic grill and filter. Metal housing and fan blades. Click-fit design installs into enclosure wall. Snap over grill with paper filter. 73db rating. Terminal block electrical connection.

SPECIFICATIONS

• Pull Type Fan
• Model Number SF1346433
• Flow 571 CFM max.
• Voltage 400/460 AC
• Amperage 0.27 Amps
• Power 172 Watts
• Speed 3050 RPM
• Operating Temperature Range Min. 5° F to Max. 140° F
• IP Rating 54
• Mount 8 holes on 5-15/16" to 11-7/8" x 5-15/16" to 11-7/8" centers
• Cutout Dimensions 11.5" x 11.5"
• Blade Dia. 7-7/8"
• Number of Blades 7
• Size 12-3/4" x 12-3/4" x 6"
• Shpg. 13 lbs.
