Product Description
35 PITCH ANSI ROLLER CHAIN SPROCKETBrand new. ANSI standard 35 pitch roller chain sprocket. Bored to size. One-piece carbon steel forged construction with hardened teeth and black oxide finish. Two set screws. Set screws are located directly over the keyway and 90° from keyway. Keyway is on center line of tooth.
SPECIFICATIONS
- Pitch 35
- Number of Teeth 15
- Bore Size 5/8"
- Model Number 35BS15H-3/4
- Outside Diameter 1.99"
- Hub Diameter 1-11/32"
- Hub Type B (Hub on one side)
- Length Through Bore 3/4"
- Keyway Size 3/16" wide x 3/32" depth
- Shpg. 0.5 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 1-2413-15-B
PDF Page Catalog298-116.pdf
Badges regular-stock
Bore Fractional 5/8''
Pitch 35
Teeth 15
![15 Tooth 5/8" Bore 35 Pitch Roller Chain Sprocket 35BS15H-5/8 [601078]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/2561/101117/1-2413-15-B__74000.1762806520.jpg?c=1 "15 Tooth 5/8\" Bore 35 Pitch Roller Chain Sprocket 35BS15H-5/8 [601078]")
![15 Tooth 7/8" Bore 35 Pitch Roller Chain Sprocket 35BS15H-7/8 [601080]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/2597/101121/1-2413-15-D__33498.1762806521.jpg?c=1 "15 Tooth 7/8\" Bore 35 Pitch Roller Chain Sprocket 35BS15H-7/8 [601080]")
![15 Tooth 7/8" Bore 35 Pitch Roller Chain Sprocket 35BS15H-7/8 [601080]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/2597/101122/1-2413-15-D_1__64324.1762806521.jpg?c=1 "15 Tooth 7/8\" Bore 35 Pitch Roller Chain Sprocket 35BS15H-7/8 [601080]")
![21 Tooth 5/8" Bore 35 Pitch Roller Chain Sprocket 35BS21H-5/8 [601097]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/2622/101155/1-2413-21-B__53081.1762806527.jpg?c=1 "21 Tooth 5/8\" Bore 35 Pitch Roller Chain Sprocket 35BS21H-5/8 [601097]")
