Product Description
80 PITCH ANSI ROLLER CHAIN SPROCKETBrand new. ANSI standard 80 pitch roller chain sprocket. Bored to size. One-piece carbon steel forged construction with hardened teeth and black oxide finish. Two set screws. Set screws are located directly over the keyway and 90° from keyway. Keyway is on center line of tooth.
SPECIFICATIONS
- Pitch 80
- Number of Teeth 16
- Bore Size 1-3/8"
- Model Number 80BS16H-1-3/8
- Outside Diameter 5.63"
- Hub Diameter 4'
- Hub Type B (Hub on one side)
- Length Through Bore 1-1/2"
- Keyway Size 5/16" wide x 5/32" depth
- Shpg. 6 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 1-2145-16-I
PDF Page Catalog298-117.pdf
Badges regular-stock
Bore Fractional 1-3/8''
Pitch 80
Teeth 16
![16 Tooth 1-3/8" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/8 [600633]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/1813/100408/1-2145-16-I__47315.1762806370.jpg?c=1 "16 Tooth 1-3/8\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/8 [600633]")
![16 Tooth 1-3/16" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/16 [600841]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/2309/100785/1-2145-16-G__06078.1762806448.jpg?c=1 "16 Tooth 1-3/16\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/16 [600841]")
![16 Tooth 1-3/16" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/16 [600841]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/2309/100786/1-2145-16-G_1__65025.1762806448.jpg?c=1 "16 Tooth 1-3/16\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/16 [600841]")
![16 Tooth 1-5/8" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-5/8 [600629]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/1730/100400/1-2145-16-L__70442.1762806368.jpg?c=1 "16 Tooth 1-5/8\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-5/8 [600629]")
![16 Tooth 1-5/8" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-5/8 [600629]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/1730/100401/1-2145-16-L_1__80797.1762806368.jpg?c=1 "16 Tooth 1-5/8\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-5/8 [600629]")
![16 Tooth 1-3/4" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/4 [600631]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/1770/100404/1-2145-16-M__49681.1762806369.jpg?c=1 "16 Tooth 1-3/4\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/4 [600631]")
![16 Tooth 1-3/4" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/4 [600631]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/1770/100405/1-2145-16-M_1__49153.1762806369.jpg?c=1 "16 Tooth 1-3/4\" Bore 80 Pitch Roller Chain Sprocket 80BS16H-1-3/4 [600631]")
![12 Tooth 1-3/8" Bore 80 Pitch Roller Chain Sprocket 80BS12H-1-3/8 [600675]](https://cdn11.bigcommerce.com/s-3nwcvn3gzw/images/stencil/500x659/products/1892/100488/1-2145-12-I__21989.1762806386.jpg?c=1 "12 Tooth 1-3/8\" Bore 80 Pitch Roller Chain Sprocket 80BS12H-1-3/8 [600675]")
