Product Description
60 PITCH ANSI ROLLER CHAIN SPROCKETBrand new. ANSI standard 60 pitch roller chain sprocket. Bored to size. One-piece carbon steel forged construction with hardened teeth and black oxide finish. Two set screws. Set screws are located directly over the keyway and 90° from keyway. Keyway is on center line of tooth.
SPECIFICATIONS
- Pitch 60
- Number of Teeth 18
- Bore Size 1-3/8"
- Model Number 60BS18H-1-3/8
- Outside Diameter 4.70"
- Hub Diameter 3-1/2"
- Hub Type B (Hub on one side)
- Length Through Bore 1-1/4"
- Keyway Size 5/16" wide x 5/32" depth
- Shpg. 3 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 1-2125-18-I
PDF Page Catalog298-117.pdf
Badges regular-stock
Bore Fractional 1-3/8''
Pitch 60
Teeth 18
