2.14 cu in Auburn 630105 L35 Cartridge Hydraulic Piston Motor [904896]

Product Description

2.14 cu in Variable Displacement Hydraulic Piston Motor
New, AUBURN GEAR model 630105 L35 type variable displacement cartridge hydraulic piston motor.  Pilot operated servo valve on motor controls speed. Pilot source required for operation to change displacement. Case drain must have a line connected back to reservoir.  Crossover to Danfoss LC 35,15cc min.

SPECIFICATIONS

• Disp. Range   0.92-2.14 cu. in. / rev.
• Control Valve  Pilot operated
• Pilot Control Valve Pressure 203-1000 PSI
• Motor Type Piston
• Pressure 2030 PSI Cont.
                    4350 PSI Max.
• Flow 33 GPM max.
• Torque Theoretical 347 lbf-in/1000 PSI
• Speed 5300 RPM max.
• Rotation Reversible
• Mount 2 bolt on 155mm (6.1") bolt circle with 165mm (5.315") pilot
• Pilot Extension 83mm (3.267")
• Shaft 1" dia. 15 tooth spline x 1.25" long
• Work Ports  SAE 12
• Pilot Control Port SAE 6
• Case Drain SAE 8
• Size 11-1/2" x 7-1/2" x 13-1/4"
• Shpg. 36 lbs.
