2 HP Special Duty 3450 RPM 115/230 Volt AC Air Compressor Motor Century B381 [501432]

Product Description

2 HP SPL 115/230 VAC 3450 RPM COMPRESSOR DUTY MOTOR
Brand New, Century model B381 electric air compressor motor. Special duty motor designed to replace motors on compressors. High torque design for compressor duty applications. Overload protection with manual reset. Welded base. Capacitor start/ capacitor run.

Confirm your motor name plate data tag including voltage, amperage, speed, frame and shaft diameter to match this motor specifications for proper operation.

SPECIFICATIONS

• Brand Century
• Model B381
• Power 2 HP Definite Purpose Special Compressor Duty
• Voltage 115/230 AC
• Amperage 15.0/7.5 Amps
• Speed 3450 RPM
• Rotation CCW
• Phase 1
• Service Factor 1.00
• Bearings Ball
• Enclosure ODP
• Duty Continuous
• Frame M56
• Mount 4 bolt base 4-7/8" x 3" centers
• Shaft 5/8" dia. x 1-3/4" w/ 3/16" keyway
• Size 9-1/2" x 6-1/2" x 8"
• Shpg. 29 lbs.
