Product Description
40 PITCH ANSI ROLLER CHAIN SPROCKETBrand new. ANSI standard 40 pitch roller chain sprocket. Bored to size. One-piece carbon steel forged construction with hardened teeth and black oxide finish. Two set screws. Set screws are located directly over the keyway and 90° from keyway. Keyway is on center line of tooth.
SPECIFICATIONS
- Pitch 40
- Number of Teeth 20
- Bore Size 3/4"
- Model Number 40BS20H-3/4
- Outside Diameter 3.46"
- Hub Diameter 2-5/8"
- Hub Type B (Hub on one side)
- Length Through Bore 1"
- Keyway Size 3/16" wide x 3/32" depth
- Shpg. 1.33 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 1-2123-20-C
PDF Page Catalog298-116.pdf
Badges regular-stock
Bore Fractional 3/4''
Pitch 40
Teeth 20
