Product Description
3/4 HP 3600 RPM 115/230 VAC 56C FACE AND BASE MOUNT MOTORBrand new, LEESON model C6C34FK36 F general purpose electric motor. Capacitor start. Steel housing. No thermal overload protection. Made in the USA.
SPECIFICATIONS
- Catalog Number 112135
- Power 3/4 HP
- Voltage 115/208-230 AC
- Amperage 10/5.2-5 Amps
- Speed 3600 RPM
- Rotation Reversible
- Phase 1
- Service Factor 1.15
- Bearings Ball
- Enclosure TEFC
- Duty Continuous
- Frame 56C
- Face Mount
Four 3/8"-16 tapped holes on
5-7/8" diameter bolt circle - Rigid Base Mount
Four 0.34" diam. holes on 4-7/8" x 3" centers - Shaft 5/8" diam. x 1-7/8" w/ 3/16" keyway
- Size 9.25" x 8.89" x 9.05"
- Shpg. 26 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 10-2749
PDF Page Catalog298-134.pdf
Badges made-in-usa,regular-stock
Enclosure TEFC
Frame 56C
HP 3/4
RPM 3450
Rotation Reversible
Voltage 115/230 Volt AC
