3/4 HP 3450 RPM 115/230 Volt AC Pool Pump Motor Ameriblue B1244 [501285]

Product Description

3/4 HP POOL PUMP MOTOR

New, AMERIBLUE B1244 by BLUFFTON MOTOR WORKS pool pump motor. Ideal replacement motor for pool, jet, and other industrial pump applications. Smooth portion of shaft measures 1-9/16" from the bearing overall length 2-1/16". Automatic thermal overload protection.

SPECIFICATIONS

• Power 3/4 HP
• Voltage 115/230 AC
• Amperage 12.8/6.4 Amps
• Speed 3450 RPM
• Rotation CCW
• Phase 1
• Service Factor 1.27
• Bearings Ball
• Enclosure ODP
• Duty Continuous
• Frame 56Y
• Mount Square flange 4 bolt on 7-1/8" diam. B.C.
• Shaft 5/8" diam. x 2-1/16" w/ 1/2"-20 RH threaded end
• Size 10-7/8" x 6-5/8" x 6-5/8"
• Shpg. 24 lbs.
