Product Description
3.92"(100mm) x 16.25"(413mm) x 1.77"(45mm) DOUBLE ACTING HYDRAULIC CYLINDERUnused old inventory. Double acting hydraulic cylinder. Numbers on cylinder T5225258.
| SPECIFICATIONS | |
|
|
| END MOUNTINGS | |
|
|
Product Videos
Custom Field
Legacy Part Number 9-20350
Badges surplus-item,last-one
Base End Tang
Base End Pin Size 40mm
Bore Range1 3'' - 3.9''
Construction Type Welded
Max PSI Over 2500 PSI
Ports BSPP
Retracted Length 30'' - 35.9''
Rod Dia 100mm
Rod End Threaded
Stroke 16.25
Stroke Range1 12'' - 17.9''
