3 HP 3600 RPM 230/460 3Ph Saw Arbor Motor WEG 00336ES3ESA80SL [501456]

Product Description

SAW ARBOR 3 HP 3500 RPM MOTOR
New, WEG 00336ES3ESA80SL saw arbor motor. Compact motor with cast iron frame that ensures high outputs with smaller frame. It was especially designed for application on circular saws, miter saws, metal cutoff saws, routers, disc sanders, and wood milling machines.

SPECIFICATIONS

• Power 3 HP
• Voltage 208-230/460 VAC
• Phase 3 Ph
• Frequency 60 Hz
• Amperage 9.49-8.58/4.29 Amps
• Speed 3500 RPM
• Rotation CW
• Service Factor 1.00
• Bearings Ball
• Thermal Overload Protection None
• Enclosure TEFC
• Duty S6
• Frame 80S
• Base Mount Four 0.58" holes on 10-1/2" x 7-1/2" centers
• Shaft M30 x 3.5 (left)
• Arbor Dimensions 120mm dia. x 32.5mm
• Size 18-1/2" x 10-1/2" x 6-1/2"
• Shpg. 132 lbs.
