30:1 Right Angle Cast Iron Worm Gear Reducer 0.47 HP 56C Right Output Worldwide HDRF-133-30-R-56C [601916]

Product Description

30:1 RIGHT ANGLE WORM GEAR REDUCER
Brand new, WorldWide Electric right-angle worm gear reducer. Standard NEMA-C motor mounting flange. Cast iron housing. Interior oil channel directly guides and constantly lube bearings. Embedded double-lip oil seals. Tapered roller bearings on output and input shafts. Double bearings used on both shafts. A set of four tapped mounting holes on top and bottom of housing. Shipped filled with Mobil #SHC632 synthetic oil for the "A" position. (Refer to installation and maintenance manual for oil capacity for different mounting positions)

SPECIFICATIONS

• Brand WorldWide Electric
• Model Number HDRF-133-30-R-56C
• Box Size 133 (1.33" Center of Input Shaft to Center of Output Shaft)
• Ratio 30:1
• Input Speed 1750 RPM max.
• Output Speed 58 RPM max.
• Mechanical HP (1.0 SF) Ratings
    Input HP 0.47 HP
    Output Torque 336 in-lb.
    Output HP 0.31 HP
• Thermal Capacity Ratings
    Input HP 0.31 HP
    Output Torque 221 in-lb.
    Output HP 0.20 HP
• Efficiency 66%
• Overhung Load 300 lbs.
• Output Shaft Thrust Load 300 lbs.
• Output Shaft Centerline Height 1.718"
• Motor Mount NEMA 56C w/ four 0.433" dia. holes on 5.875" dia. B.C.
• Input Bore 5/8" keyed bore
• Output Type Right Hand Shaft
• Output Shaft 5/8" dia. x 2" keyed
• Mount Two sets of four 5/16"-18 tapped holes on 3-1/4" x 2" centers
• Size 6" x 6-1/2" x 6-1/2"
• Shpg. 18 lbs.
