38.0 cu in Parker TG0625LS080 Hydraulic Wheel Motor [906688]

Product Description

38.0 cu in PARKER TG0625LS080 HYDRAULIC WHEEL MOTOR
New, Parker TG0625LS080 hydraulic wheel motor. Rugged construction throughout. The entire powertrain is continually washed in cool, high flow fluid to assure long life. Roller vanes and sealed commutator maintain high efficiency and provide smooth low speed performance.

SPECIFICATIONS

• Brand Parker
• Model TG0625LS080
• Family TG
• Displacement 38.0 cu. in. / rev.
• Motor Type LSHT Torqmotor
• Rotation Reversible
• Pressure:
     1750 PSI cont.
     2250 PSI int.
• Torque:
     8727 in-lbs. cont.
     11424 in-lbs. int.
• Speed:
     122 RPM cont.
     182 RPM int.
• Flow:
     20 GPM cont.
     30 GPM int.
• Mount 4 Bolt wheel mount on 5.81" bolt circle w/ 3-1/4" O.D. pilot
• Shaft 1-1/4" Tapered x 2-3/8" shaft w/ 5/16" key and threaded end w/ castle nut
• Ports SAE 10
• Case Drain None
• Size 12-1/2" x 5" x 5"
• Shpg. 44 lbs.
