4" 28 CFM 24 Volt DC Fan SF0424413 [501197]

Product Description

4" GRILL 28 CFM 24 VOLT DC FAN
New, Pentair fresh air enclosure filter fan model SF0424413. High airflow and low noise for cooling electrical equipment or general air circulation. Black plastic grill. Air is pulled through the plastic grill and filter. Plastic housing with plastic blades. Click-fit design installs into enclosure wall. Snap over grill with foam filter. 30db rating. Wire leads electrical connection.

SPECIFICATIONS

• Pull Type Fan
• Model Number SF0424413
• Flow 28 CFM max.
• Voltage 24 VDC
• Amperage 0.11 Amps
• Power 2.2 Watts
• Speed 3300 RPM
• Operating Temperature Range Min. 14° F to Max. 131° F
• IP Rating 54
• Mount 4 holes on 3-5/8" x 3-5/8"
• Cutout Dimensions 3-5/8" x 3-5/8"
• Blade Dia. 3"
• Number of Blades 5
• Size 4-1/8" x 4-1/8" x 2-3/8"
• Shpg. 0.85 lbs.
