Product Description
4.9375" STROKE 120 VAC LINEAR ACTUATORNew, ICON HEALTH AND FITNESS model# 320496 capacitor-start linear actuator. Power extend and power retract, rated to push up to 900 lb., retract under no load. Hall effect sensor connected to internal gearing.
SPECIFICATIONS
- Voltage 120 VAC, 60 Hz
- Amperage 1.55 Amps
- Capacity 900 lb. Push
- Thread 3/4"-6 Acme thread
- Stroke 4-15/16"
- Extension Speed 0.087" / sec. (no load)
- Extension Time 57 seconds to Full Stroke, No Load
- Limit Switches NA
- Direction Reversible
- Duty Intermittent
- Retracted length 8-1/2"
- Rod end pin hole 3/8"
- Base end pin hole 1/2"
- Size 9-1/2" x 4-1/4" x 3-1/8"
- Shpg. 6 lb.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 5-1871
PDF Page Catalog298-146.pdf
Badges surplus-item,last-one
Load Rating 500 to 999 lbs.
Stroke 4'' to 7.99''
Voltage 120 Volt AC
