5" x 2" Rigid Plate Caster WC6650R-01-PAL [700557]

Product Description

5" x 2" RIGID PLATE CASTER
Brand New, WC6650R-01-PAL rigid plate caster with polyurethane coated aluminum wheel. Case hardened double ball raceways provide extra capacity and durability. Top plate and legs are made out of 1/4" cold forged steel and corrosion-resistant zinc plated finish. 5/8" nut and bolt kingpin and 2-1/2" for spacing with 1/2" zerk axle and lock nut. Precision molded high quality polyurethane chemically bonded to a smooth polished aluminum core. The combination of slight crowned tread and high quality annular ball bearings provide exceptionally low effort to start up and push a load. Offers floor protection, is non marking, and non-conductive. Resistant to most chemicals, oils, grease, cleaning agents, solvents, and water. Great for foodservice and institutional applications. Meets NSF and UL sanitation standards.

SPECIFICATIONS

• Model Number WC6650R-01-PAL
• Wheel Diameter 5" dia.
• Wheel Width 2" Wide
• Load Capacity 900 lbs.
• Mounting Height 6-1/2"
• Top Plate 4" x 4-1/2" x 1/4" thick
• Mount 4 holes 2-5/8" x 3-5/8" slotted to 3" x 3" centers
• Bolt Holes 3/8" dia.
• Wheel Tread Material Polyurethane
• Wheel Tread Color Blue
• Wheel Tread Durometer 95 Shore A
• Caster Wheel Core Material Aluminum
• Caster Wheel Bearing Roller
• Wheel Temperature Rating -40ºF to 180ºF
• Shpg. 6 lbs.
