55.2 Gallon Hydraulic Reservoir Buyers Products UR50S [902363]

Product Description

UPRIGHT STEEL HYDRAULIC RESERVOIR

Brand new, BUYERS model UR50S hydraulic reservoir. Constructed of 12 gauge black powder coated steel. 3/4" NPT magnetic drain plug. Chrome breather cap with filler basket. Oil level gauge with temperature indicator. Internally baffled between suction and return ports. Suction,return and drain ports on bottom of the tank. Welded mounting brackets can be drilled custom installation. Mounting kit included. Mounting brackets must be drilled to attach mounting kit. Four "L" shaped brackets elevate tank off mounting surface. Mounting kit includes hardware to prevent twisting of the mounting frame from damaging the reservoir.

SPECIFICATIONS

• Brand Buyers Products
• Model Number UR50S
• Nominal Oil Capacity 55.2 Gallon
• Usable Oil Capacity 50 Gallon
• Ports:
     Suction 2" NPT x one
     Return 1-1/4" NPT x one
     Drain 3/4" NPT x one
• Mount
     Welded mounting angles w/ Mounting Kit
• Mounting Holes None
• Size 34" x 14-3/4" x 25-1/2"
• Shpg. 157 lbs.
