Product Description
7.5 HP 3450 RPM MOTORNew, CENTURY model# TCP71006 inverter duty rated motor. 1" I.D. lifting tab included.
SPECIFICATIONS
- Power 7-1/2 HP
- Voltage 230/460 VAC
- Amperage 19/9 Amps
- Speed 3450 RPM
- Rotation Reversible
- Phase 3
- Service Factor 1.15
- Bearings Ball
- Enclosure TEFC
- Duty Continuous
- Frame 213JM
- Face Mount Four 1/2"-13 tapped holes on 7-1/4" B.C., 8-3/8" pilot
- Base Mount Eight 7/16" holes on 8-1/2" x 1-1/2" x 5-1/2" x 7" centers
- Shaft 1-1/4" dia. x 4-1/4" long, Stepped down to 1" dia., Stepped down to 7/8" dia. w/ 3/16" wide keyway, tapped 3/8-16
- Size 16-7/8" x 15" x 10-7/8"
- Shpg. 240 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Truck true
Prop65 true
Legacy Part Number 10-3089
PDF Page Catalog298-132.pdf
Badges surplus-item,last-one
Enclosure TEFC
Frame 213JM
HP 7-1/2
RPM 3450
Voltage 230/460 Volt AC
