8 GPM 2 Stage Hydraulic Pump Dynamic GP-CBN-080-P-C [902018]

Product Description

8 GPM 2 STAGE HYD PUMP
Brand new, two stage HI/LO pressure hydraulic gear pump. Ideal for applications such as log splitters, presses and other equipment where rapid movement of the cylinder at low pressure is required prior to automatically switching to the high pressure mode to meet load requirements. The change from LO to HI pressure is automatic with the LO stage pressure preset at 650 PSI. Cast iron construction.  Ball bearing equipped on shaft end for belt or direct drive applications. Minimum of 5 HP required for gas engine use.

SPECIFICATIONS

• Brand Dynamic
• Model Number 70864
• Build Number GP-CBN-080-P-C
• Displacement:
    0.130 cu. in. / rev. HI press. stage
    0.385 cu. in. / rev. LO press. stage
• Pump Type Gear
• Rotation CW
• Pressure: 3000 PSI max.
• Speed: 3600 RPM max.
• Flow:
    2 GPM HI press. stage
    8 GPM LO press. stage
• Unloader Adj. Range 400-900 PSI
• Overhung Shaft Load Up to 90 lbs.
• Mount 4 bolt USA 4F17
• Shaft 1/2" dia. x 1-1/2" long keyed
• Rqd. Filtration 25 micron
• Inlet Port 1" ID Hosebarb
• Outlet Port 1/2" NPT
• Size 4-3/4" x 5-1/8" x 3-3/8"
• Shpg. 10 lbs.
