90/180 Volt DC Variable Speed Control w/Potentiometer Minarik MM23001C-000D [500204]

Product Description

SCR MOTOR SPEED CONTROL FOR DC MOTORS
Brand new Minarik model MM23001C. Adjustable SCR speed controller for permanent magnet or shunt wound, brush type motors. Ideal for motors in the range of 1/8 HP to 2 HP. Compact design in industry standard MM footprint. Optional heatsink (sold separately) can be added to boost output current capacity. Integral potentiometers for setting minimum and maximum speed, acceleration and deceleration, torque and IR compensation. Speed control potentiometer included.

SPECIFICATIONS

• Brand Minarik
• Model MM23001C
• Input 115 or 230 Volt AC, 50/60 Hz
• Armature voltage (115 Volt AC IN) 0-90 Volt DC
• Armature voltage (230 Volt AC IN) 0-180 Volt DC
• Output Amperage 5 Amps, 10 Amps w/heatsink
• Output Power Range @ 90 Volt DC 1/8 HP to 1 HP @ 90 Volt DC
• Output Power Range @ 180 Volt DC 1/4 HP to 2 HP @ 180 Volt DC
• 1% regulation over 60:1 speed range
• Size 4.31" x 3.59" x 1.59"
• Shpg. 2 lbs.
