3 HP 230/460 Volt AC 3505 RPM 3PH WEG 25314-SHU Motor [501609]

Product Description

• Brand WEG
• Model Number 25314-SHU
• Power 3 HP
• Voltage 230/460 AC
• Phase 3
• Frequency 60 Hz
• Amperage 7.34/3.67 Amps
• Speed 3505 RPM
• Rotation Reversible
• Service Factor 1.15
• Bearings Ball
• Enclosure TEFC
• Duty Continuous
• Frame 56HJ
• Base Mount Six 1-1/8" x 5/16" elliptical slots on 4-7/8" x 2" x 5" centers
• Face Mount Four 3/8"-16 threaded holes in motor face on 5-7/8" B.C., 4-1/2" pilot
• Shaft 5/8" dia. x 2-1/2" overall length w/ 7/16"-20 x 5/8" threaded end and 1/4"-28 tapped
• Size 15-1/2" x 10" x 7-1/2"
• Shpg. 54 lbs.
