Hydraforce Flow Regulator Valve Cartridge Valve FR10-30A-0-N-4.0 [901153]

Product Description

HYDRAFORCE FLOW REGULATOR VALVE FR10-30A-0-N-4.0

New, Hydraforce. A screw-in, cartridge-style, fixed orifice, pressure-compensated, bypass-type hydraulic flow regulating valve, with limited range adjustment from a pre-determined nominal setting.
The FR10-30A maintains a constant flow rate out of port 3 regardless of load pressure changes in the circuit downstream of port 3, or in the bypass leg at 2. The valve will pressure-compensate once a minimum pressure drop (determined by spring adjustment setting) is achieved from 1 to 3. This value will range from approximately 4.8 to 13.8 bar (70 to 200 psi). The cartridge may be adjusted to �25% of nominal setting. At nominal setting, pressure drop is approximately 9 bar (130 psi). Flow out of priority port 3 may vary based on input flow amount, particularly with lower temperatures and increased fluid viscosities. Settings may need to be established through correlation study. Consult factory.

SPECIFICATIONS

• Brand HydraForce
• Model FR10-30A-0-N-4.0
• Type Flow Regulator, Pressure Compensated
• Pressure Rating 3000 PSI max.
• Pressure Setting None
• Flow 6 GPM max.
• Fits into VC10-3 Cavity
• Features 1/4" Hex Allen head adjustment option, 3.0 - 5.0 GPM standard setting, Cartridge Only
• Overall Size 5-3/16" x 1-1/8" dia.
• Shpg. 1 lb.
