Product Description
1/2 HP 1725 RPM 208-230/460 VOLT AC 3PH MOTORBrand new, Marathon model# 5K35MNB117. General purpose motor. No thermal overload protection.
SPECIFICATIONS
- Manufacturer Marathon
- Model 5K35MNB117
- Power 1/2 HP
- Voltage 208-230/460 AC
- Phase 3
- Frequency 60 Hz
- Amperage 2.1-2.2/1.1 Amps
- Speed 1725 RPM
- Rotation Reversible
- Service Factor 1.25
- Bearings Ball
- Thermal Overload Protection None
- Enclosure TEFC
- Duty Continuous
- Frame 56
- Base Mount Four 1-1/4" x 5/16" elliptical slots on 5" x 3" centers
- Shaft 5/8" dia. x 1.88" overall length w/ 3/16" wide x 1.38" long keyway
- Size 9.01" x 8.12" x 6.89"
- Shpg. 22 lbs.
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 10-3374
PDF Page Catalog298-132.pdf
Badges surplus-item,last-one
Enclosure TEFC
Frame 56
HP 1/2
RPM 1750
Voltage 208-230/460 Volt AC
