1/2 HP 1725 RPM 120/240 Volt AC Marathon Electric Motor 5KCR46MN0055Y [501455]

Product Description

• Manufacturer Marathon
• Model Number 5KCR46MN0055Y
• Power 1/2 HP
• Voltage 120/240 V AC
• Phase 1
• Frequency 60 Hz
• Amperage 5.6/2.8 Amps
• Speed 1725 RPM
• Rotation Reversible
• Service Factor 1.25
• Bearings Ball
• Thermal Overload Protection Manual
• Enclosure TEFC
• Duty Continuous
• Frame 56C
• Base Mount Four 7/8" x 5/16" elliptical slots on 4-7/8" x 3" centers
• Face Mount Four 3/8"-16 threaded holes in motor face on 5-7/8" B.C., 4-1/2" pilot
• Shaft 5/8" dia. x 1-7/8" overall length w/ 3/16" wide x 1-3/8" long keyway
• Size 9.72" x 9.07" x 8.40"
• Shpg. 33 lbs.
