1.7 cu in Variable Axial Piston Pump Rexroth A4VG28HWDL1/32R-NSC10N005E-S [906604]

Product Description

1.7 CU IN REXROTH A4VG28HWDL1/32R-NSC10N005E-S VARIABLE AXIAL PISTON PUMP
New, Rexroth A4VG28HWDL1/32R-NSC10N005E-S variable axial piston pump. Proportional control hydraulic mechanical servo with pressure cut-off and neutral position switch. High pressure direct operated relief valve fixed setting with bypass. High-pressure relief valves with integrated boost function. Adjustable pressure cut-off is standard.

SPECIFICATIONS

• Manufacturer Rexroth
• Model A4VG28HWDL1/32R-NSC10N005E-S
• Series 32
• Disp. 1.7 cu. in. / rev.
• Pump Type Piston
• Rotation CW
• Pressure:
     5801 PSI nominal pressure
     6527 PSI peak pressure
• Speed:
     500 RPM min.
     4250 RPM max.
• Flow: 31.4 GPM
• Mount Two bolt SAE B
• Shaft 1" dia. x 1-1/2" long 15T spline w/ 3/8"-16 TPI tapped end
• Inlet Port 3/4" 4 bolt flange, code 61
• Outlet Port 3/4" 4 bolt flange, code 61
• Size 10-1/2" x 8-1/2" x 11-1/4"
• Shpg. 68 lbs.
