Prince Auto Cycle Valve, SAE Ports, 3000 PSI RD525MMEE5A4B1F [903094]

Product Description

PRINCE AUTO-CYCLE CONTROL VALVE
Brand new PRINCE. Special Auto-Cycle valve allows operator to completely cycle (out and back) a double acting cylinder by only one handle movement.
Ideal for log splitter applications
Both levers are pulled out to detent position, cylinder extends and at end of forward stroke one lever automatically returns to neutral and cylinder reverses. When fully retracted second lever returns to neutral. (3 work ports are used, two are tied to together and then run to rod end of cylinder, third connects to base end of cylinder). Can be converted to power beyond with optional sleeve (not included).
SPECIFICATIONS

• Open Center
• Spools Special For 1 DA Cylinder
• Double pressure relief detent
• Flow Max 25 GPM
• Pressure Max 3000 PSI
• Relief valve Adj.1500-3000 PSI factory set @ 2000 PSI
• In/Out Ports SAE 12
• Work Ports SAE 12
• Size 9-1/2" x 7-1/2" x 3-1/4"
• Shpg 29 lbs.
