12 & 24 Volt DC Pump Controller Shurflo LCB-G 902-200 [200884]

Product Description

PUMP CONTROLLER
New, Shurflo LCB-G pump controller. Outdoor enclosure with water level sensors and sensor wire. Designed as an interface between a DC (Solar)-Pump and a DC power source, like solar panels, wind generators, batteries etc.. The main function of this controller is to maximize the daily water output while providing protection for the pump. The controller can be used in 12V and 24V systems. Made to work with Shurflo 9300 series submersible pumps (Not available from Surplus center).

SPECIFICATIONS

• Brand Shurflo
• Model Number LCB-G
• Part Number 902-200
• Max. Input Voltage 45 Volt DC
• Start Up Voltage 12.5 V
• Start Up Voltage with Series 25.0 V
• Max. Output Voltage 29 Volts
• Max. Power Consumption of the PV-Pump-System 150 Watts
• Max. Output Current 7 Amps
• Power Consumption 25 mA
• Ambiente Temperature 14-113°F (-10-45°C
• Size 6-7/8" x 4-3/8" x 2-1/4"
• Shpg. 10 lbs.
