Product Description
182TC/256TC TO SAE A PUMP MOUNT
Brand new, Hydra-Mount model E502-A2 aluminum alloy pump mount for connecting standard NEMA frame electric motors with 7-1/4" bolt circle (see frame numbers below) to hydraulic pumps with SAE A 2 bolt (4-3/16" c/c with 3-1/4" pilot) flange. One access opening with cover plate.
SPECIFICATIONS
- Motor Frames
182TC and 184TC
213TC and 215TC
254TC and 256TC - Pump Mount SAE A 2 bolt
- Total Length 5"
- Size 8-3/4" dia. x 5"
- Shpg. 5 lbs.
Product Videos
Custom Field
Legacy Part Number 1-3249
Badges regular-stock
