1.25 cu in Cross Hydraulic Motor 40MH12DACSC 360012 [901474]

Product Description

CROSS HIGH SPEED HYDRAULIC MOTOR

Brand new, Cross hydraulic gear motor. Model 40MH12DACSC. Pressure balanced loading plates for high efficiency. Aluminum body for good heat dissipation. Pressure lubricated Teflon impregnated sleeve bearings. Internal check valves eliminate need for case drain at shaft seal pressures under 250 PSI.

SPECIFICATIONS

• Brand Cross Mfg.
• Model 40MH12DACSC
• Cross Item #360012
• Displacement 1.25 cu. in. / rev.
• Pressure 3000 PSI max.
• Speed 3000 RPM max. continuous
• Flow 10.9 GPM for 1800 RPM
• Power 13.5 HP at 1800 RPM, 2500 PSI
• Torque 475 in-lbs. at 2500 PSI
• Rotation Reversible
• Mount SAE A 2 bolt
• Shaft 5/8" dia. x 1-1/4" long with 5/32" wide keyway
• Ports SAE 12
• Drain Port 1/4" NPT
• Size 4-13/16" x 5-1/8" x 4-15/16"
• Shpg. 9 lbs.
