2x33x1.25 Double Acting Hydraulic Cylinder Tandem Right [901870]

Product Description

2" x 33" x 1.25" DOUBLE ACTING WELDED CYLINDER - TANDEM RIGHT
New, old inventory. Two welded hydraulic cylinders of different strokes connected together opposingly. Ported with crossovers to allow both to operate at the same time. The long cylinder has a stroke of 26", the short cylinder is 7" stroke for a combined stroke of 33". Transfer tube, both ports at base end. Internal threaded glands on each cylinder. Each cylinder has a flat base and a clevis on each rod end.
Cylinder barrel stamped with "10821, 218-901, IR70638523".
3/16" barrel tubing thickness.

SPECIFICATIONS
Double Acting Bore x Stroke 2" x 33" Pressure 3000 PSI max. Rod Dia. 1-1/4"	Ports SAE 8 Retracted Length 38-3/4" Shpg. 51 lbs.

END MOUNTINGS
Long Cylinder	Short Cylinder
Rod End Clevis Inside Width 1-1/4" Outside Width 2" Throat Depth 1-3/8" Pin Hole 1"	Rod End Clevis Inside Width 1-1/4" Outside Width 2" Throat Depth 1-3/8" Pin Hole 1"
