Product Description
5:1 GEAR REDUCERNew, WORLDWIDE ELECTRIC cast iron right-angle worm gear-reducer. Left hand output shaft when viewed from motor flange. Can be easily swapped to give right hand output. Tapped mounting holes on top and bottom of case. Mounting base supplied.
SPECIFICATIONS
- 5:1 gear ratio
- 3.91 HP input
- 1750 RPM input
- 350 RPM output
- 640 in-lbs output torque
- 2.5" Output centerline height
- Motor mount: 56C
- 5/8" dia. keyed hollow input
- 1-1/8" diam. x 2-3/8"keyed output shaft
- 2.88"x 5" mgt bolt pattern
- Overall size 8-5/8" x 6-1/2" x 8-1/8"
- Shpg 41 lbs
| California Residents |
|
WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
Product Videos
Custom Field
Prop65 true
Legacy Part Number 13-237-5-56C
Badges surplus-item,last-one
Motor Mount 56C
Output Shaft Left
Ratio 5:1
Dimensional Diagram dr13-237-5-56c.pdf
