5 HP Special Duty 3450 RPM 230 Volt AC Air Compressor Motor Century B813 w/ Y56HZ Frame [501440]

Product Description

5 HP SPL 3450 RPM 230 VOLT AC AIR COMPRESSOR DUTY MOTOR CENTURY B813
Brand new, Century model# B813 air compressor motor. Special duty motor designed to replace motors on compressors. High starting torque on start-up to achieve a higher starting load required in air compressor applications. Capacitor-start, capacitor-run. Heavy-duty construction ensures motor durability. Thermal overload protection with manual reset.

Confirm your motor name plate data tag including voltage, amperage, speed, frame and shaft diameter to match this motor specifications for proper operation.

SPECIFICATIONS

• Brand Century
• Model B813
• Power 5 HP Definite Purpose Special Compressor Duty
• Voltage 230 AC
• Phase 1
• Frequency 60 Hz
• Amperage 22.0 Amps
• Speed 3450 RPM
• Rotation CCW
• Service Factor 1
• Bearings Ball
• Thermal Overload Protection Manual Reset
• Enclosure ODP
• Duty Continuous
• Frame Y56HZ
• Base Mount Six 1-1/4" x 5/16" elliptical slots on 3" x 4.88" to 5" x 4.88" centers
• Shaft 7/8" dia. x 2.31" w/ 3/16" keyway
• Size 14.06" x 9.07" x 9"
• Shpg. 45 lbs.
