50 HP 3550 RPM 200 Volt AC 3PH Marathon Motor [501384]

Product Description

50 HP 3550 RPM 200 VOLT AC 3PH MARATHON MOTOR
New, Marathon pump motor model# FVJ324TTDP17015AAL.

SPECIFICATIONS

• Power 50 HP
• Voltage 200 AC
• Phase 3
• Frequency 60 Hz
• Amperage 143 Amps
• Speed 3550 RPM
• Rotation Reversible
• Service Factor 1.15
• Bearings Ball
• Enclosure ODP
• Duty Continuous
• Frame 324JP
• Base Mount Four 0.66" diam. holes on 12-1/2" x 10-1/2" centers
• Face Mount Four 5/8"-11 tapped holes on 11" diameter bolt circle
• Shaft 1-38" dia. x 3-1/2" stepped down to 1-1/4" dia. x 2-1/4" w/ 1-4" keyway
• Size 29-3/8" x 19-3/4" x 15"
• Shpg. 422 lbs.
