23 CFM Air Compressor Two Stage 5 HP CI5 [400100]

Product Description

CAST IRON 2 STAGE COMPRESSOR
Brand new, cast iron compressor designed for heavy duty applications where high air volume and pressure are required along with extra long life. All cast iron including inner and after coolers to reduce air temperature. Low speed gives quieter operation, less vibration. Complete with oil sight glass, unloader valve (for no-load starting) and safety pop off valve. Ships without oil. Add compressor oil pror to use.

SPECIFICATIONS

• 5 HP Model
• Displ 23 CFM
• 2 Cylinder
• 17 CFM at 175 PSI
• Two stage
• 805 RPM max
• Bore/Stroke
  4-1/8" X 3-1/2" 1st stage
  2-1/8" X 3-1/2" 2nd Stage
• 175 PSI max
• Cast iron
• Cooling fan/pulley
• Port 3/4" NPT
• 17" pulley - 2 groove B belts
• Mtg pattern 8" x 9"
• 17" X 19" X 21"
• TRUCK FREIGHT
• Shpg 250 lbs
